• Model NO.：SJ-L SERIES
• Engagement System：Full Intermeshing
• Screw Channel Structure：Deep Screw
• Exhaust：Exhaust
• Automation：Automatic
• Computerized：Computerized
• Capacity：40-350kg,H
• Transport Package：in Nude
• Trademark：SANLONG
• Origin：Wenzhou
• HS Code：8477800000
• Production Capacity：40-350kg,H

Basic Info.

Model NO. SJ-L SERIES Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Exhaust Automation Automatic Computerized Computerized Capacity 40-350kg/H Transport Package in Nude Trademark SANLONG Origin Wenzhou HS Code 8477800000 Production Capacity 40-350kg/H

Product Description

SJ-L Series Plastic Tape Extruder is designed according to our research on the basis of actual application in China plastic woven sacks industry. It is the most popular model in China market featured in being economical, practical, and reliable. It mainly adapts to the raw material of thermo-plasticity such as polythene (PE) and polypropylene (PP) and so on. It can also make full use of recycled material outputting low intensity of plastic tape, which brings enormous economic profit by reducing production cost.



Model	Screw dia. (mm)	Screw L/D	Screw speed (r/min)	Die length (mm)	Drawing Speed (m/min)	Stretch Ratio	Main Motor (KW)	Drawing Machine Power (KW)	Heating Power (KW)	Thickness Of Plastic tape (mm)	Extrusion Capacity (Kg/h)
SJ-L145-24	145	1: 26	10-80	2400	15-120	4-7	55	11	120	0.03-0.10	200-245
SJ-L145-25	145	1: 26	10-80	2500	15-120	4-7	55	11	130	0.03-0.10	200-245
SJ-L155-26	155	1: 27	10-80	2600	15-120	4-7	55	15	140	0.03-0.10	210-270
SJ-L155-28	155	1: 27	10-80	2800	15-120	4-7	75	15	165	0.03-0.10	220-285
SJ-L160-30	160	1: 28	10-80	3000	15-120	4-7	75	15	175	0.03-0.10	230-300
