PVC Profile Extruding Machine/PE Profiles Extrusion Making Machine

Jiangsu Faygo Union Machinery Co., Ltd.
  • Type：Profile Extruder
  • Plastic Processed：PE
  • Product Type：Profile Extrusion Molding Machine
  • Feeding Mode：One Feed
  • Assembly Structure：Separate Type Extruder
  • Screw：Single-Screw

Base Info

  • Model NO.：SJSZ65
  • Engagement System：Full Intermeshing
  • Screw Channel Structure：Deep Screw
  • Exhaust：Exhaust
  • Automation：Automatic
  • Computerized：Computerized
  • Material：PVC Powder
  • Finial Products：PVC Profile
  • Name：PVC Profile Production Line
  • Screw Material：38crmoaia
  • Heating：Omron Electric
  • Screw Cooling：Fan
  • Motor Brand：Siemens
  • Transport Package：Covered by PE Film
  • Specification：CE& ISO2001
  • Trademark：Jiangsu FAYGO Union Machinery Co., Ltd.
  • Origin：China
  • HS Code：847000
  • Production Capacity：200kg,H

Description


ModelMax.wide(mm)Extruder modelMax output(kg/h)Drive motor power(kw)FG108108SJZ51/10510018.5FG180180SJZ51/105 or SJZ55/110100/15018.5/22FG240240SJZ65/13225037FG300300SJZ65/13225037FG400400SJZ80/15635055FG500500SJZ80/15635055FG600600SJZ80/15640075
PE profile production line Configuration:
1.Conical twin Screw Extruder ABB frequency converter, SIEMENS contactor, Japan, Motor power:75KW 2.Calibration unit calibration plate:1500mm×500mm 4couples 3. Cooling tank and bracket length:6000mm trimming knife:3 sets 4. Haul-off unit  5. Cutting unit 6. Stacker 7. Mould (T-Die )
Contact Supplier
Technology Details
PE profile production line Packaging & Delivery

Packaging Details:		internal inspection,boot test,Moistureproof processing,composite material box,load container.
Delivery Detail:60 days after receiving downpayment

PE profile production line for profiles With Price features:
1) Mainly used to produce the PVC window profiles, plastic decorative plates and PE
foam profiles
2) Use frequency conversion for speed regulation
3) Has super-taper twin-screw extruder with temperature controlling instrument in the screw core
4) Saves power by 30% - 40%
5) The rigid gear surface of the reducer can be operated continuously for a long
time without trouble
6) Operation and mold changing are smooth and steady7) Long usage life
8) Can produce steel plastic profiles by changing the wood imitation foaming profile
mold, combines with one set of steel liner conveying devices
