• Model NO.：Rl Series
• Technical Service：Provide
• Transport Package：According to Detail Spec
• Trademark：HC
• Origin：Changzhou China
• Production Capacity：3sets,Month

Basic Info.

Model NO. Rl Series Technical Service Provide Transport Package According to Detail Spec Trademark HC Origin Changzhou China Production Capacity 3sets/Month

Product Description

General descriptions
This equipment is a new (fusibility) moulding granulator. Liquid cool and become solid during the transportation. Raw materials whose melting point in the range of 50 degree-300 degree all can granulate. No dust, improving producing environment. Having some economical value(saving energy, cheap container packing), its fast to change new products, granules have beautiful appearance with equable size and half ball, granules are easy to be packed, transported and stored, and also it is easy to calculate for the user. Granule can be mixed and melted again, which realizes continuous production. Labor intensity is low from feeding to packaging, having stepless speed adjust, adjustable flux, conbenient operation. It is widely used for petroleum, fine chemical such  industries. This equipment can produce different granule, such as strip, clump and piece. Poisonous raw materials can be operated in close container.

Production scene



Material to be dried
The product is suitable for all kinds of material to be granulated that has 50 degree-300 degree of melting point (or softening point) and material with the characteristic of "super-cooling crystal".



Technical parameter

Type	RL60-A	RL60-B	RL60-C	RL60-D	RL120-A	RL120-B	RL120-C	RL120-D
Effective heat transfer area(m2)	2.6	3.6	4.6	5.3	7.3	9.3	10.8	16.6
Power of main /auxiliary motor(kw)	1.5/0.75	1.5/0.75	1.5/1.1	1.5/1.1	3/1.5	3/1.5	3/1.5	4/2.2
Overall dimensions(mm)	5600×1200 ×1800	7200×1200 ×1800	8800×1200 ×1800	10050×1200 ×1800	7200×1700 ×1800	8800×1700 ×1800	10050×1700 ×1800	14800×1700 ×1800
Productive capacity(kg/h)	80-100	100-150	120-180	150-250	300-380	360-420	380-500	500-800
Total weight (kg)	1360	1580	1880	2060	2380	2590	2830	4210
