Sjcot Series 2000mm Film Width Rotary Die Head HDPE/LDPE Film Blowing Machine
Zhejiang Songshan Machinery Co., Ltd.- Raw Material：HDPE, LDPE, LLDPE; Virgin and Recycled
- Certification：CE
- Condition：New
- Temperature Control：10zones
- film Thickness：0.008mm-0.15mm
- Warranty：1 Year
Base Info
- Model NO.：SJCOT-65
- Automatic：No
- Die Size：600mm
- Blow Moulding Type：Extrusion Blow Moulding
- Blower：7.5kw
- Power(W)：18.5kw
- Gearbox：173
- Transport Package："Plastic Film; , Wooden Boxes, or as Required"
- Trademark：songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
SJCOT-55
SJCOT-60
SJCOT-65
Features
Raw Material
HDPE, LDPE, LLDPE; Virgin and Recycled
Film Width
800mm
1500mm
2000mm
Average Output
80Kgs
120Kgs
150Kgs
Film Thickness
0.008mm-0.15mm
Power supply
380V, 3Phase, 50Hz
Weight
3000KG
3500KG
4000KG
Dimension
6M×5M×5.5M
6M×6M×6M
6M×7M×7.5M
Extrusion Unit
Screw& Barrel Diameter
50mm×2
55mm×1
55mm×2
60mm×1
60mm×2
65mm×1
Screw& Barrel L/D ratio
32:1
Motor
15KW×2
22KW×1
18.5KW×2
30KW×1
30KW×2
45KW×1
Gearbox
146/173
146/173
173
Die Head Type
Rotary Die Head
Die Size
400MM
450MM
600MM
Heating
50kw
60kw
80kw
Blower
7.5KW
Film
Taking-up Tower
Upper Tower Type
Rise and Fall
Roller Length
1000mm
1700mm
2200mm
Roller Working Way
Opened and Tightened by Air Cylinders
Take Up Motor
1.5KW
Winding Station
Winder Type
Double winding station
Rollers Length
1000mm
1700mm
2200mm
Torque Motor
15N/M×3
Max. Winding Diameter
600mm
Control Panel
Electronics
Top China Brand
Inverter
3pcs
Optional Equipment
Hopper loader, Corona, Mechanical Screen Changer
