Superior Quality Semi-Auto Blowing Machine Dy-12000A

ZHENGZHOU KING PACK LONG MACHINERY CO., LTD.
  • Type：Stretch Blow Molding Machine
  • Raw Material：PET
  • Making Method of Parison：Stretch Blow
  • Automation：Non-Automatic
  • Certification：CE, ISO9001:2008
  • Material：Stainless Steel 304

Base Info

  • Model NO.：DY-1200A
  • Professional Certification：ISO1900,Ce
  • PLC：Delta
  • Transport Package：Wooden Box
  • Specification：1350× 700× 850mm
  • Trademark：Kingpack
  • Origin：Wenzhou China
  • HS Code：8477401000
  • Production Capacity：500PCS,Year

Description

Superior Quality Semi-Auto Blowing Machine Dy-12000A

 DY-1200A    ContainerProduct materialPET,PP,PE Volume0.1- 2L  Theoretical output600-1000 pcs per hour Preform length15-350 Preform inner diameterΦ5-38MouldingMax.mould plate Dimension(L x W)350×380 Max.mould thickness180 Clamping force45 Mould opening stroke160Machine size and weight Main machine (L x W x H)160×60×161cm Main machine weight500 Heater (L x W x H)187×63×145cm Heater weight250 Power17.5
  HP air compressor
Air compressorUnit0.6M3/25KG
VolumeM30.6
PressureKg30
Speedr/min800
PowerKW7.5
Overall Dimensionmm1350×700×850
Weightkg320
Air Filter:
Refining-FilterUnit1.0M3/30Kg
Flow CapacityM3/Min1
Max. work pressureMpa3.0
Inlet Temp.ºC≤50
Cold Mediummm650*250*250
WeightKg15
Production Flow:
Superior Quality Semi-Auto Blowing Machine Dy-12000A
Machine Assemble:
Superior Quality Semi-Auto Blowing Machine Dy-12000A

Packing&Delivery:
Superior Quality Semi-Auto Blowing Machine Dy-12000A
Professional Certification:
Superior Quality Semi-Auto Blowing Machine Dy-12000A
