HDPE Car Oil Bottles Made by Automatic Blow Moulding Machine
Zhangjiagang Dawson Machine Co., Ltd.- Type：Extrusion Blow Molding Machine
- Raw Material：HDPE
- Making Method of Parison：Extrusion-Blow Molding
- Automation：Automatic
- Computerized：Non-Computerized
- Certification：CE
Base Info
- Model NO.：ABLB75I-1
- Max Product Volume：8 Liters
- Output Capacity：90-100PCS,H
- Screw Diameter：75mm
- Screw L/D Ratio：24 L,D
- Screw Drive Power：22 Kw
- Screw Heating Capacity：6 Kw
- Heating Zone：4 Zones
- HDPE Output：100kg,H
- Oil Pump Drive Power：11 Kw
- Clamping Force：78kn
- Weight：4.8t
- Platen Moving Stroke：520mm
- Air Pressure：0.8MPa
- Air Displacement：0.8m3,Min
- Water Flow：80L,Min
- Transport Package：Film Packing
- Specification：ABLB75
- Trademark：Dawson
- Origin：Zhangjiagang, Jiangsu, China
- HS Code：8477301000
- Production Capacity：as Per Samples
Description
0.3-0.6MPa
