Two Layer Coextrusion Blown Film Machine (2SJ-50/65)

Zhejiang Zhuxin Machinery Co., Ltd.
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1500mm
  • Screw Diameter：70mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：2SJ-50,65
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008
  • Transport Package：Standard Wooden Case,Stretch Film Package
  • Specification：CE,ISO9001
  • Trademark：Changyin
  • Origin：China
  • HS Code：84773000
  • Production Capacity：500sets,Year

Description

Basic Info.

Model NO. 2SJ-50/65 Machine Weight 4T Certification CE, ISO9001:2008 Transport Package Standard Wooden Case/Stretch Film Package Specification CE/ISO9001 Trademark Changyin Origin China HS Code 84773000 Production Capacity 500sets/Year

Product Description

Feature:
1) The machine plasticizing two identical or different raw substances by two extruder extrude them to the complex machine head, then produces the co-extruding molded complex film. By this way, it makes possible to enhance the film physical performance, rigidity, good insulation-proof and impenetrability.

2) Features: The machine entails advanced consecutive rotation machine head, ensures products more smooth and homogeneous, meets the quality requirements of the subsequent working of the packing and printing machine. It is suitable to produce complex bead sheen film, complex hydro-packing film, insulation film, multi-function farming film, etc. Its application range is gradually widening to the target of plastic product development. 3) Material: LDPE. HDPE. LLDPE

Technical data:
1. Model: 2SJ-50
Diameter of screw: 50*2
L/D: 28: 1
Reduced diameter of film: 800mm
Single-face thickness of film: 0.015-0.1mm Max. Output: 40kg/h
Power of main motor: 11*2kw
Heating power: 26kw
Outline dimension: 4200*2200*4000mm
Weight: 3T

2. Model: 2SJ-55
Diameter of screw: 55*2
L/D: 28: 1
Reduced diameter of film: 1000mm
Single-face thickness of film: 0.015-0.1mm
Max. Output: 65kg/h
Power of main motor: 15*2kw
Heating power: 30kw
Outline dimension: 4600*2400*4600mm
Weight: 3.5T

3. Model: 2SJ-60
Diameter of screw: 60*2
L/D: 28: 1
Reduced diameter of film: 1200mm
Single-face thickness of film: 0.015-0.1mm
Max. Output: 80kg/h
Power of main motor: 18.5*2kw
Heating power: 42kw
Outline dimension: 5000*2800*5000mm
Weight: 4.5T
