Plastic Machinery

Home > Product > Injection Molding Machine

Energy Saving Automatic Plastic Bottle Preform Injection Machine

Zhangjiagang Reliable Machinery Co., Ltd.
  • Type：Preform Injection
  • Structure：Horizontal
  • Plastic Type：Thermoplastic
  • Plasticizing Way：Plunger Type
  • Clamping Way：Hydraulic & Mechanical
  • Automation：Automatic

Base Info

  • Model NO.：SZ-700A
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008
  • Product Name：Automatic Plastic Bottle Preform Injection Machine
  • Feature：Energy Saving
  • Clamping Force：700kn
  • Opening Stroke：290mm
  • Suitbale Material：PP PE PS Pet HDPE
  • After-Sales Service Provided：Engineers Available to Service Machinery Overseas
  • Condition：New Injection Molding Machine
  • Max. Clamping Force：700 Kn
  • Max. Opening Force：290 mm
  • Pump Motor Power：9 Kw
  • Transport Package：Wooden Case
  • Specification：CE ISO ISO
  • Trademark：Reliable Machine
  • Origin：Jiangsu Zhangjiagang
  • HS Code：8477101090
  • Production Capacity：5 Set, Month

Description


Data

Max. clamping force

KN

700

Max. opening force

mm

290

(V×H)Space between tie bars

mm

320x320

(min-max)

Mould height

mm

100-300

Max. daylight

mm

590

Ejector force

KN

25

Ejector stroke

mm

60

Ejector quantity



1

Screw diameter

mm

32

35

95

Screw L/D ratio

L/D

20

18.8

19.9

Theoretical shot volume

cm 3

112.5

135

287

Plasticising weight(PS)

g

101

121

261

Injection pressure

l Kg/cm

232

194

1640

Theoretical injection rate(PS)

g

62

72

499

Screw torque

N.m

390

Max. screw rotate speed

r/min

220

Injection stroke

mm

140

Pump motor power

KW

9

Pump pressure

KG/cm

16

Heating power

KW

6.2

Heating zone



4

Size

m

3.55×1.2×1.6

Net weight

t

2.7

International designation



700-230

Energy Saving Automatic Plastic Bottle Preform Injection Machine
Energy Saving Automatic Plastic Bottle Preform Injection Machine
Energy Saving Automatic Plastic Bottle Preform Injection Machine
Energy Saving Automatic Plastic Bottle Preform Injection Machine

What Reliable Machinery Co., Ltd can offer you?
Our products include: Liquid filling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, plant protein drink, etc. ), Barreled filling line (3-5 gallon) Water treatment machines, Labeling & packing machines, semi-automatic /full automatic bottle blowing machines, and injection molding machines.
Reliable Machinery can provide turn-key services for customers, from plant layout, equipment manufacture and production line installation to operator training and other after-sales services.
Energy Saving Automatic Plastic Bottle Preform Injection Machine


ZHANGJIAGANG RELIABLE MACHINERY CO., LTD
