100ml~200ml Small Bottle Double Station Ten Die-Head Blow Molding Machine

Suzhou OTO Machinery Co., Ltd.
  • Warranty：One Year
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：TKS-D85-10
  • Certification：CE, ISO9001:2008, QS, UL
  • After-sales Service：One Year
  • Station：Double
  • Die Head：Ten
  • Screw Diameter：φ85mm
  • L/D：25:1
  • Output：130kg,H
  • Screw Motor Power：37kw
  • Clamping Force：110kn
  • Mold Moving Stroke：800mm
  • Center Distance：70mm
  • Oil Pump Motor：15kw
  • Total Power：77kw
  • Average Power：45kw
  • Air Pressure：0.8MPa
  • Dimension：4280*4490*2670mm
  • Weight：11.0 Ton
  • Transport Package：Wooden Case
  • Specification：51CBM
  • Trademark：OTO
  • Origin：China
  • HS Code：847740
  • Production Capacity：100 Sets,Year

Description

Basic Info.

Model NO. TKS-D85-10 Certification CE, ISO9001:2008, QS, UL After-sales Service One Year Station Double Die Head Ten Screw Diameter φ85mm L/D 25:1 Output 130kg/H Screw Motor Power 37kw Clamping Force 110kn Mold Moving Stroke 800mm Center Distance 70mm Oil Pump Motor 15kw Total Power 77kw Average Power 45kw Air Pressure 0.8MPa Dimension 4280*4490*2670mm Weight 11.0 Ton Transport Package Wooden Case Specification 51CBM Trademark OTO Origin China HS Code 847740 Production Capacity 100 Sets/Year

Product Description

Double Station Ten Cavities Blow Molding Machine for 100ml~300ml Small Bottle, Milk Bottle
Product Capacity is around 5700b/h, 150ml, 6.5g as reference
Normally Output is around 120000~140000 per day for samll bottle, it depends on volume and weight of the bottle
