• Model NO.：CHSJ-M
• Machine Weight：1.4t
• Certification：CE, ISO9001:2008
• Rotation Speed of Screw：10-120r,Min
• Extrusion Capacity：30-35kg,H
• Main Motor Power：7-10kw
• Thickness of The Film：0.006-0.10mm
• Transport Package：Wooden-Box,Nude
• Specification：SGS
• Trademark：Chengheng
• Origin：China
• HS Code：8477309000
• Production Capacity：100 Sets,Year

ModelM-40/500  M-45/600  Width of the filmT-shirt bag150-300mm  150-400mmFlat bag100-450mm  150-550mmThickness of the film0.006-0.10mmThe max output30g/h   35kg/h
According to different width,thickness of film, die size and raw material characteristics to changeRaw materialLDPE/LLDPE/HDPEPower consumption7kw/h   10kw/hWeight1300kg   1400kg Overall dimension(L*W*H)m2.2×1.4×2.2Extruder unitDiameter of screwΦ40   Φ45  38CrMoALA  wearproof Alloy steel,five years guaranteeL/D ratio of screw30:1Rotation speed of screw10-120r/mBarrel FanZone 3 barrels install over-temperature fanGear box133#  146#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation systemMain motor7.5kw  11kw
100% Original three-phase variable frequency motor  Equipped with inverter controlDie head unitDie diameter50mm   60mm  80mm With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effectCool unitAir ring typeHDPESingle outlet air ringAir ring materialHigh quality Taiwan cast aluminum alloy air ringBellow power1.5kw   1.1kw
Shanghai production of high-pressure mute fanTraction unitWidth of take up roller500mm  600mmTraction roller materialsilicone roller
NBR rollerTake up motor                       1.1kw  1.5kw
Installation of RV series reducer variable frequency motor inverter controlTake up speed100m/minEmbossing rollerhot embossing unit
cold embossing unitLambdoidal boardWooden flannel wrappedGusset equipmentModular rack type
Independent Split  Bubble stabilizing ringElectric aluminum roller guide
Manual wood floor Guide rollerAluminum guide roller (HV300-HV700) surface treatmentWinding unitWinding typeSurface friction rewinding, manually change the volumeDrive typeTorque motor equipped RV reducerFilm expanding rollerSmoothing rollerElectric control cabinetlow-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control tableComputer control type7-inch touch screen + process control system
Automatic air supply device
Service

1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.One year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.

Order step

step1. Please let us know which product you like. the model and size, the offers will be sent to you within 24 hours.
step2.  We make proforma invoice (PI) for you.
step3. Please check and confirm the PI
step4. Once we confirmed the order, please pay it soon.
step5. After payment, all goods will be sent to you in the delivery time.
