• Model NO.：QS-DC45*2
• Raw Material：PE
• Maximum Folding Width of Film：600mm
• Screw Diameter：45mm
• Automation：Automatic
• Computerized：Computerized
• Machine Weight：3
• Certification：CE
• Condition：New
• Cool：Natural Cooling
• Rewinder：Single Rewinder
• Die Head：Two Color Special Head Die
• Output：45kg,H
• Automatic：Yes
• Blow Moulding Type：Extrusion Blow Moulding
• Key Selling Points：Easy to Operate
• Power(W)：15-22kw
• Year：2019
• Number of Layers：Two-Layer
• Dimension(L*W*H)：4800*1900*4100mm
• Application：Film
• Voltage：380V
• Transport Package：Seaworthy
• Specification：50kgs
• Trademark：queensense
• Origin：Zhejiang, China
• Production Capacity：25 Set,Sets Per Month

Type

QS-DC45×2

QS-DC55×2

Diameter of Screw

45mm×2

55mm×2

Screw L/D Ratio

28:1

28:1

Screw Spead

10-110r/min

10-110r/min

Max.Output(kg/h)

45kg/h

60kg/h

Max.Layflat Width (mm)

550mm

650mm

Film Thickness(mm)

0.006-0.10mm

0.006-0.10mm

Power of Main Motor

11kw

18.5kw

Total Power

30kw

40kw

Weight of Machine

2200kg

3000kg

Overall Dimensions(L×W×H)mm

4800×2200×3600

5000×2400×4200
