• Automation：Automatic
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Power：380V,60Hz
• Transport Package：Wooden Pallet and Easy Film
• Specification：4200 x 2000 x 4000mm
• Trademark：WT
• Origin：China
• Production Capacity：1000

Basic Info.

Automation Automatic Computerized Computerized Certification CE, ISO9001:2008 Power 380V,60Hz Transport Package Wooden Pallet and Easy Film Specification 4200 x 2000 x 4000mm Trademark WT Origin China Production Capacity 1000

Product Description

WT-C SERIES BIG SIZED HDPE/LDPE FILM BLOWING MACHINE SERIES


Introduction:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps in crease the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene (HDPE) and linear low density polytene (LLDPE), It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.



Main Technical Parameters:


Model	WT-C-2500
Screw Diameter	110MM
Screw Ratio	L/D28:1
Screw Speed	10-100r/min
Power of Main Motor	75KW
Power of traction main motor	5kw
Main Output	180kg/h
Max.Folding Width of Film	2500mm
Single-sided Thickness of Film	0.02-0.1mm
Overall Dimensions	9000x4200x9600mm










Q1. What is your terms of packing?
A: The normal package is making a pallet to protect the machine at the bottom and wrap the whole machine with plastic film packing. If export to EUROPEAN countries, the wooden box will be fumigated. we  use PE film for packing or pack it according to customers special request.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF

Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
