Automatic Pet Bottle Blowing Molding Machine
Zhangjiagang King Machine Manufactory Co., Ltd.- Type：Extrusion Blow Molding Machine
- Automatic Grade：Automatic
- Warranty：12months
- After Sale Service：Engineers Available to Service Overseas
- Main Material：SUS304,SUS316L
- Control：PLC
Base Info
- Model NO.：KM-A4
- Cavity：4 Cavities
- Capacity：3500bph for 500ml
- Max Volume：2L
- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
- Transport Package：Standard Export Packing
- Specification：CE Certificate, ISO9000: 9001
- Trademark：KING MACHINE
- Origin：China
- HS Code：8477
- Production Capacity：10sets Per Month
Description
KM-A4Productivity Depend on bottle design 3200-4000PCS/H Product type Body diameter 20mm-100mm Height 50mm-350mm Neck diameter 15mm-38mm Mold Cavity 4cavities Mold thick 240mm Mold 500*500mm Main machine Electrical source power 380v 3Phase /220v 3Phase 50/60HZ Rated Power 49kw Really use power 14kw Dimension of main machine 3600*1630*2050mm Weight of main machine 2600kg Air source LP air compressor 1.6m3/min 1.0MPa 1set (15KW) HP air compressor 1.0m3/min 3.0MPa 2sets (each set 11KW) Air dryer 2.0m3/min 3.0MPa 1set Cooling water Cooling water 15L/min Size L*W*H 1908*1858*1920mm Weight 3600kg Auxiliary equipment(preform unscrambler) L*W*H 2000*950*2480mm Weight 250kg Resin available PET Main part: Pneumatic part Valve SMC Cylinder Electric part PLC LG Mitsubishi Operating system LG /HITECH Relay OMRON Infrared thermometer America raytek Note All of the electrical components adopts CEULCCC approved international advanced high-tech product.
