Double Colors Film Blowing Machine (MD-45X2-600)

Ruian Mingde Machinery Co., Ltd.
  • Type：Dual Head Plastic Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：45mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：MD-45X2-600
  • Machine Weight：1200kgs
  • Certification：CE, ISO9001:2008
  • Main Motor：Siemens Beide
  • Frequency Inverter：Taiwan Delta
  • Temperature Controller：Xiamen Yudian
  • Color：Green
  • Transport Package：Nude Packing or Wooden Case Packing
  • Specification：CE
  • Trademark：Mingde
  • Origin：China
  • HS Code：8477209000
  • Production Capacity：50sets,Year

Description

MD-45×2-600Main Technical Parameters Model
MD-45×2AMD-45×2BSuitable Material
HDPEMax Film Width(mm)
600600Film Thickness(mm)
HD:0.008-0.08Max Extrusion Output HD
55kg/hr45kg/hrExtrusion unit   Gear Box
2×133133×2Screw Diameter(mm)
φ45×2φ45×2Screw L/D Ratio
28:128:1Screw's Material

Barrel Materail
38 CRMOALABarrel's Cooling Fan
250W×2×2250W×2×2Thermo Control (zone)
33Driving Motor (kw)
157.5×2Out of  Proportion
1:11:10Extrusion Die   Die Size (mm)
HD:φ60Screen Changer
Standard manualThermo Control (zone)
2Air Ring (mm)
φ620Cooling Blower (kw)
2.2Center Steady Stick
1 PCSTake-UP Unit    Roller Width (mm)
φ138×650Embossing Roller Width
550mmTake-UP Motor (kw)
0.75Take-UP Speed(M/min)
10-8010-60Height adjustable type
700mmWinding Unit    Type OF Winder
Surface Friction Winder Roller Width (mm)
700Winding Motor (N.M)
6Winding Speed(M/min)
10-8010-60Voltage
380V, 50HZ, 3PHASECover Dimensions (m)
4.0×3.0×4.34.0×3.0×4.3
