• Model NO.：PPSJ120
• Engagement System：Full Intermeshing
• Screw Channel Structure：Deep Screw
• Exhaust：Exhaust
• Automation：Automatic
• Computerized：Computerized
• PLC Controll：High Speed
• Big Output：Low Consumption
• Polish Roller：Two Station Rewinder
• Servo Motor：T-Die
• Melting Pump：Distributor
• Thickness Tolerance：Smoth Sheet Thickness
• Transport Package：Wooden Pallet
• Specification：PP-HFSJ100-33,700B
• Trademark：Polyprint
• Origin：China
• HS Code：84772090
• Production Capacity：Max. 250 Kg,H

Basic Info.

Model NO. PPSJ120 Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Exhaust Automation Automatic Computerized Computerized PLC Controll High Speed Big Output Low Consumption Polish Roller Two Station Rewinder Servo Motor T-Die Melting Pump Distributor Thickness Tolerance Smoth Sheet Thickness Transport Package Wooden Pallet Specification PP-HFSJ100-33/700B Trademark Polyprint Origin China HS Code 84772090 Production Capacity Max. 250 Kg/H

Product Description

Main Parameter:
Suitable Material: PS, PP, PE
Sheet Thickness: 0.25-2.0mm
Max. Sheet Width: 700mm
Sheet: 1 layer
Max. Output: 250kgs/h

1- Screw  Diameter	Φ 100mm        origin:   Zhoushan
2- Screw  L/D	33: 1
3- Barrel  Heating  Power	5  kw/section  X  5section
4- Barrel  Screw  Material	38CrMOALA
5- Screw  Heating  Treatment	Nitrogen  Hardness≥ HV850,   Depth0.5-0.7mm
6- Barrel  Heating  Treatment	Nitrogen  Hardness≥ HV950,   Depth  0.5-0.7mm
7- Heater	Casting  Aluminum  Heater
8- Main  Driving  Motor	75  kw  motor
9- Controller	Japan  Yaskawa  inverter
10- Screw  Rev  Speed	0- 100  rpm
11- Barrel  Cooling  Method	Fan  cooling  with  240W
12- Gear  Box	Hard  tooth  surface  gear  box    Origin:   Zhoushan
13- Dryer	400kgs
14- Autoloader	500kg/h
