• Automation：Automatic
• Computerized：Computerized
• Certification：CE, ISO9001:2008
• Condition：New
• Transport Package：Film Packing
• Specification：4*6*2.5m
• Trademark：WT
• Origin：China
• Production Capacity：100

Basic Info.

Automation Automatic Computerized Computerized Certification CE, ISO9001:2008 Condition New Transport Package Film Packing Specification 4*6*2.5m Trademark WT Origin China Production Capacity 100

Product Description

HQ Plastic Grind Milling Machine



Introduction:

This Plastic Grinding Milling Granulator adopts Japanese design principles, employs the principles of grinding rapidly,etc.

Main Functions:

1. Recycle the waste materials and leftover bits and pieces of various flexible plastic films, bags, filament, ribbons, pieces, and pipes such as polyvinyl chloride, polyethylene of higher density, and linear polyethylene of lower density, and put them into reproduction.
 2. Recycle and reproduce the grinding and granulating of degrading plastic films and angle materials.
3. Grind chemical fiber waste materials, and process the waste filament that has been put into reproductions.
4. The machine is applied in many respects. It can be substitute for blending machine or dryer.

Main Technical Variables:


Model	HQ-150	HQ-300
Capacity of Barrel	150L	300L
Output Capacity	60-80kg/h	120-160kg/h
Main Motor Power	18kw	37kw
Water Adding Device	125w	125w
Heating Power	1.5kw	1.5kw
Rotary Speed of Main Shaft	660r/min	660r/min
Overall Dimensions	1500×700×1400mm	1800×900×1500 mm
