HDPE Pipe Pre-Insulated Extrusion Line
Qingdao Huashida Machinery Co., Ltd.- Type：Pipe Extruder
- Plastic Processed：PE
- Product Type：Granulating Extruder
- Feeding Mode：One Feed
- Assembly Structure：Integral Type Extruder
- Screw：Multi-Screw
Base Info
- Model NO.：HSD
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Don′t Exhaust
- Automation：Automatic
- Computerized：Computerized
- Application：Producing Pre-Insulated Pipe Casing Pipe
- Transport Package：Standard Package
- Specification：EN253, EN448, EN728, ISO1133, ISO8501-1. ISO9001
- Trademark：HSD
- Origin：Qingdao China
- HS Code：8477209000
- Production Capacity：1000unit,Year
Description
Basic Info.
Model NO. HSD Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Don′t Exhaust Automation Automatic Computerized Computerized Application Producing Pre-Insulated Pipe Casing Pipe Transport Package Standard Package Specification EN253, EN448, EN728, ISO1133, ISO8501-1. ISO9001 Trademark HSD Origin Qingdao China HS Code 8477209000 Production Capacity 1000unit/YearProduct Description
HDPE Plastic Pipe Extruder Pipe Pre-Insulated Pipe Extrusion LineVacuum calibrating method pre-insulated pipe outside casing extrusion line is the most advanced and popular machinery in the world.
This pipe extrusion line mainly includes single screw extruder, molds, vacuum calibrating water tank, spray water cooling tank, haul-off machine, cutting machine and bracket.
(MODELS: PE-365/760 PE-420/960 PE-850/1380 PE960/1680)
The line is an integration design composed by extrusion, vacuum calibrating, cooling, pulling, cutting, stacker. Great performance in automatic operation, extrusion capacity, steady and long service life etc. Especially compared with the line use internal pressure method, vacuum calibrating method is much better than it for stiffness, pressure resistance and smooth surface.
Plastic Pipes produced by this line has excellent stiffness, flexibility, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage and so on. It has become the first choice for the city gas pipe, water supply pipe, foundation pipe, landfill collection pipe, watermain, geothermal heating etc.
| Style | PE-110-550 | PE-365-760 | PE-850/1380 | PE-960/1680 |
| Main extruder | SJ-75/33 | SJ-90/33 | SJ-120/33 | SJ-150/33 |
| Pipe diameter | Φ110-550mm | Φ365-760mm | Φ 850-1380mm | Φ 960-Φ 1680mm |
| Capacity | 220-280kg/h | 400~500 kg/h | 700~900 kg/h | 900-1100kg/h |
| Installed power | 160kw | 250 kw | 440 kw | 580kw |
| Length | 35m | 36 m | 40 m | 45m |
