• Model NO.：GWG63-GWG800
• Condition：New
• Product Name：PVC Drainage Pipe Extrusion Line
• Another Name：PVC Draining Pipe Making Machine
• Processing Type：Pipe Extrusion
• Raw Material：PVC Powder and CaCO3
• Usage：Drainage Pipe
• Motor：Simens
• Inverter：ABB Brand
• Contactor：France Schneider Contactors
• Temperature Control：Japan Omron
• Output：180- 1100kg,H
• Transport Package：PE Film Winding Wrapping
• Specification：16-800mm
• Trademark：GPM
• Origin：Shanghai
• HS Code：8477209000
• Production Capacity：500 Sets,Year

          SPECIFICATIONS FOR PVC DRAINAGE  PIPE PRODUCTION LINEModelPipe spec(mm)Conical twin screw extruder Max.output
(kg/h)Total power(kw)GWG63-PVCΦ20-Φ63GSZ65/132180-300104GWG160-PVCΦ63-Φ160GSZ65/132180-300105GWG250-PVCΦ75-Φ250GSZ80/156300-450110GWG315-PVCΦ200-Φ315GSZ80/156300-450216GWG450-PVCΦ200-Φ450GSZ92/188650-750290GWG630-PVCΦ315-Φ630GSZ92/188750-850350GWG800-PVCΦ500-Φ800GSZ135/31950-1100410                              Parallel twin-screw extruder technical specificationModelMotor power(kw)Screw diameter
(mm)Max.speed
(rpm)L/DMax.capacity(kg/h)Weight(kg)GSP75/2837753628:12804100GSP93/1345/55934531:14504700GSP110/3190/1101104531:16806500GSP120/31110/1321204531:18507500GSP135/311601354531:111008400

1.Extruder



Type	GSZ65 / 132
Electric control cabinet	Main transducer and feeder's transducer: TECO; Air switch: SIEMENS or CHNT
Type of Temperature control curve	Temperature fluctuating self-adjusting (PID Type)
Origin places of the speedometers	Imported brand
Pressure Display	With melt pressure display
Connection of die head with flange	By bolts
The display method of data in operating panel	Temperature meter controller Omron
Screw
Diameter	65/132mm
Effective length	1440mm
Quantity	2pcs
Material	38CrMoAlA
Mesh Type	Conical Mesh
Treatment	Nitrided
Thickness of nitrided layer	0.6-0.7mm
Total Torque	6.4KNM
Rotation speed(r/min)	1~34.7 r/min
