Automatic EPS Forming Machine
Hangzhou Fuyang Wealth Imp & Exp Co., Ltd.- Brand Name：Vst
- Model Number：Vsm100-200t
- Plastic Type：EPS
- Certificate：CE,ISO9001
- Mould Dimension：1800*1600mm
- Max Product Size：1610*1400*330mm
Base Info
- Model NO.：psz100T psz120T psz140T psz160T psz175T psz180T
- Connected Load：23.6kw
- Machine Size：5100*2610*3800mm
- Cycle Time：120-190s
- Transport Package：20ft Container, by Sea, by Train, by Truck
- Trademark：VST
- Origin：Zhejiang, China (Mainland)
- Production Capacity：20units,Month
Description
TECHNICAL DATAItem Unit VSM100T VST120T VST140T VST160T VST175T VST180T Mould Dimension mm 1000*800 1200*1000 1400*1200 1600*1350 1750*1450 1800*1600 Max Product Dimension mm 800*600*
330 1000*800*
330 1200*1000*
330 1400*1100*
330 1550*1200*
330 1610*1400*330 Stroke mm 210-1360 210-1360 270-1420 270-1420 270-1420 220-1370 Steam Entry mm 50 50 65 65 65 65 Steam Consumption Kg/cycle 6 7 9 10 10 11 Water Entry mm 50 50 65 65 65 65 Cooling water Consumption Kg/cycle 40-120 45-138 50-150 55-180 60-190 80-200 Compressed air entry mm 25 40 40 40 40 50 Compressed air consumption M³ /cycle 1.2 1.5 1.8 2 2 2.2 Vacuum pump capacity M³ /h 165 165 230 280 280 280 Connected load Kw 10.6 10.6 14.1 19.6 19.6 23.6 Overall dimension mm 4500*1640*
2700(mm) 4500*1840*
2900(mm) 4600*2140*
3100(mm) 5000*2300*
3400(mm) 5000*2450*
3500(mm) 5100*2610*3800(mm) Machine weight Kg 4500 5200 5700 7000 7500 8000 Cycle time s 60-90 60-100 60-150 90-160 90-160 120-190
