Jwell-Bm30|50|100 HDPE Plastic Recycling Agricultural Blow Molding Machine Used in 15-100L ...
ZHEJIANG JWELL PIPE EQUIPMENT CO., LTD.- Type：Extrusion Blow Molding Machine
- Raw Material：HDPE
- Making Method of Parison：Extrusion-Blow Molding
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, QS, UL, GMP
Base Info
- Model NO.：JWS plastic blow molding
- Die Head Structure：Accumulating Type
- Main Screw Diameter：80mm,90mm,100mm
- Total Power：95kw,110kw,135kw
- Max Plasticizing Capacity(PE)：120,180,190 Kg,H
- Max Product Volume：30L,50L,100L
- Model No.：Bm30|50|100 HDPE Plastic Blow Molding Machine
- Layer：Optional Double Layer Co-Extrusion System
- View Strip：Optional View Strip Line System
- Control：Optional Hydraulic Servo Control System
- Platen Size(mm)：740*740 880*880 1020*1000
- Trademark：JWELL
- Origin：China
- HS Code：84774010
- Production Capacity：1000 Set,Sets Per Year
Description
Accumulating typeMain screw diameter mm 80 90 100 Max plasticizing capacity (PE) kg/h 120 180 190 Driving motor Kw 37 45 55 Accumulating volume L 5.2 6.2 12.8 Oil pump motor power Kw 15 18.5 22 Clamping force KN 280 400 600 Space between platen mm 400-900 450-1200 500-1300 Platen size W*H mm 740*740 880*880 1020*1000 Max. mold size mm 550*650 700*850 800*1200 Heating power of die head Kw 20 28 30 Machine dimension L*W*H m 4.3*2.2*3.5 5.6*2.4*3.8 5.5*2.5*4.0 Machine weight T 12 13.5 16 Total power Kw 95 110 135
We only choose qualified supplier--Jwell excellent partner
We work closely with world famous brand,your equipment can also be equipped with any compond brand as you wish.
All Key parts: screw&barrel, T-die, roller and downstream equipment are made by Jwell factory!
Company Information
SUZHOU JWELL MACHINERY CO., LTD. is located in TaiCang city, Jiangsu province, abutting Jiading district, Shanghai City. It's high-tech manufacturer specializing in research & development and producing extrusion equipment. There are total over 1000 employees, 280 are technical and management staffs. Company has good R & D employees and experienced mechanical , electrical commissioning engineers as well as advanced mechanical machining base and normative assembly workshop.
Main products: various plastic pipes extrusion lines; various plastic profile extrusion lines; various plastic plate & sheet extrusion lines including Jwell PVC SPC Calcium-plastic Environmental Floor Extrusion lines and PC PP PE plastic hollow cross section plate extrusion line; chemical fiber spinning; microcomputer controlled automatic blow molding machines; plastic auxiliary recycling lines; various single & twin screw and barrel extruders; T die; screen exchangers; Rollers and Robots.
FAQ
Q1. Is Jwell Machinery Manufacturer?
A1: Jwell made the first Chinese screw and barrel in 1978 in brand name Jinhailuo . After more than 40 years development, JWELL is one of the biggest extrusion machine supplier in China with 300 design&test engineer, 3000 employees. We own 5 manufacturing bases and sales center in Shanghai , Suzhou , Changzhou, Zhou Shan, Dongguan China. Jwell has become the premier supplier of extrusion lines and reliable business partners. Welcome to drop in us.
Q2: How many brands does Jwell Machinery own?
A2: Jwell Machinery owns more than 20 subsidiaries, China famous brand JINHAILUO, JWELL, BKWELL, DYUN are our Trade Marks.
Q3: If we don't find what we need from your website , What should we do ? Do you make extrusion lines as per customers' specific requirement?
A3: Yes, we can provide bespoke service to customers with specific requirements. You can send the detailed requirements by email. We will check if we can develop them. We develop new machinery every month, and some of them may not yet be updated on our website.
Q4: How do you ensure your machinery and service quality?
A4: Our machines taking the European standards and follow the Germany type of business, we cooperation with International famous brands Siemens Schneider Flender Omron ABB WEG Falk Fuji etc. Our company continuously imports over 1000 international first-class high precision processing equipment such as multistage machining centers, NC lathes and CNC milling machines from Korea, Japan etc. All our processes strictly adhere to CE certification, IS09001 and 2008 quality management system . And we have 12 months quality warranty time. We testing the machine performances before each delivery. Jwell service engineers will always be here for anything you needed.
Q5: How can I order and make payments?
A5: Once clear your requirements and determined extrusion line is ideal for you. We will send technical solutions and Proforma Invoice to you. You can pay via TT bank transfer, LC as you like.
Q6: If we find your bank account or email different as before, how should we respond?
A6: Please don't send the payment and double check with us before arrange payment (Bank details will be listed in every piece of proforma invoice. )
Q7: How long is the delivery date?
A7: Usually it takes about 1 - 4 months depends on different machinery upon receipt of order advance payment.
Q8: What is your Minimum Order Quantity?
A8: One. We provide both customized extrusion lines and technical solutions. Welcome contact with us for technical innovation or improvements for your future purchasing plan.
Q9: What is your production capacity?
A9: We produce more than 2000 advanced extrusion lines every year world wide.
A10: What about shipping?
Q10: We can send the small spare parts by air express for urgent matter. And the complete production line by sea to save the cost. You can either use your own assigned shipping agent or our cooperative forwarder. The nearest port is China Shanghai, Ningbo port, which is convenient for maritime transportation.
Q11: Is there any pre-after sale service?
A11: Yes, we support our business partners by pre-after sale service. Jwell has more than 300 technical testing engineers traveling world wide. Any cases would be responded with prompt solutions. We provide training, testing, operation and maintenance service for a life time.
Q12:Are our business& money safe with Jwell Machinery ?
A12: Yes, your business is safe and your money is safe. If you check China company blacklist, you will see that it is not contain our name as we never crook our customer before. JWELL enjoys high reputation from the customers and our business and customers grows year by year.
Best regards!
Sincerely yours,
Sales Manager:Stella Xu
Jwell-BM30|50|100 HDPE Plastic Recycling Agricultural Blow Molding Machine Used in 15-100L Jerrycan Open-top Barrels and Others Chemical Packaging Products
