• Model NO.：Multi-layer
• Condition：New
• Weight：5200kg
• Transport Package：Wooden Cases
• Specification：gmp
• Trademark：SUNWAY
• Origin：Jiangsu, Tongzhou
• HS Code：8422303090
• Production Capacity：60PCS,Min

Basic Info.

Model NO. Multi-layer Condition New Weight 5200kg Transport Package Wooden Cases Specification gmp Trademark SUNWAY Origin Jiangsu, Tongzhou HS Code 8422303090 Production Capacity 60PCS/Min

Product Description

THE FEATURES OF CO-EXTRUSION TUBE
Plastic material has its own characters. In co-extrusion system, we use and combine several kinds of materials. Therefore, the characters of single layer tube can't compete with the complex characters of co-extrusion tube.
1. Glossy surface ( using: EVOH/RESIN/PE)
2. Extensive color combination ( using: PE+PEARL/PE+PLGMENT)
3. Excellent barrier property (using: PE/TIE RESIN/EVOH/TIE RESIN/PE)
4. Scratch and dust free (using: LDPE/LDPE/LLDPE)
Co-extrusion is used on pesticide container, toothpaste, side window, multicolor, long preservative cosmeticetc.
MAIN SPECIFICATIONS
1. Screw Dia(inner): φ 50mm, L/D: 30/1
2. Screw Dia(resin): φ 40mm, L/D: 28/1
3. Screw Dia(EVOH): φ 35mm, L/D: 26/1
4. Screw Dia(outer): φ 45mm, L/D: 32/1
5. Screw Type: Full Flight
6. Motor: 7.5HP× 1pcs, 5P× 2cs, 10× 1pcs
7. Water Consumption: 60L/min
8. Power Consumption: 95.5kw
9. Extrusion Linear Speed: 8m/min(φ 50mm)
10. Cutting Speed: 100pcs/min
11. Tube Dia Range: φ 19~60mm
12. Machine Size: 6800× 3500× 2300mm
13. Total New Weightx: Approx 5200kg
