• Model NO.：B. JG-II
• Engagement System：Full Intermeshing
• Screw Channel Structure：Non Deep Screw
• Exhaust：Don′t Exhaust
• Automation：Automatic
• Computerized：Computerized
• Size：6500X4000X2100mm
• Transport Package：Wooden Cases
• Specification：GMP
• Trademark：sunway
• Origin：Shanghai, China
• HS Code：8422303090
• Production Capacity：60 PCS,Min

Basic Info.

Model NO. B. JG-II Engagement System Full Intermeshing Screw Channel Structure Non Deep Screw Exhaust Don′t Exhaust Automation Automatic Computerized Computerized Size 6500X4000X2100mm Transport Package Wooden Cases Specification GMP Trademark sunway Origin Shanghai, China HS Code 8422303090 Production Capacity 60 PCS/Min

Product Description

Features:
1, Two-layer extrusion tube can reduce material cost. (using: Pearl + PE/PE + Pigment)
2, The temperature controllers of different materials can be controlled individually. In this way, we can find out the best running condition on the materials both in running fluency and dissolubility.
3, The surface of co-extrusion tubes made by two-layer machine is more glossy than the surface of mono-layer tubes.
4, Using the same material on two-layer co-extrusion can increase the water-resistance and anti-peneteration of the materials for about 20-30% (using: PE+ Pigment. Inner: Recycled material. )
MAIN SPECIFICATIONS
1, Screw Dia(inner): φ 45mm, 15HP
2, Screw Dia(outer): φ 40mm, 10HP
3, Screw L/D Ratio (inner): 32/1
4, Screw L/D Ratio (outer): 32/1
5, Screw Type: Full flight
6, Water consumption: 40L/min. 5-10C
7, Power consumption: 66kw
8, Extrusion Linear Speed: 100pcs/min
9, Cutting Speed: 100pcs/min
10, Tube Dia Range: φ 19-60mm
11, Machine Size: 6500*4000*2100mm
12, Total New Weight: Approx. 5200kg.
