• Model NO.：JC-EPEP170
• Screw Dia：170mm
• Foaming Rate：30-55times
• Product Width：600-2000mm
• Output：400kg,H
• Installed Power：198kw
• Dimensions：30X4X2.4m
• Transport Package：Packing by Film
• Specification：1 set
• Trademark：JC
• Origin：China
• HS Code：8477209000
• Production Capacity：50sets,Month

Basic Info.

Model NO. JC-EPEP170 Screw Dia 170mm Foaming Rate 30-55times Product Width 600-2000mm Output 400kg/H Installed Power 198kw Dimensions 30X4X2.4m Transport Package Packing by Film Specification 1 set Trademark JC Origin China HS Code 8477209000 Production Capacity 50sets/Month

Product Description

EPE Foam Sheet Machine (No Wave) Plastic Foam Processed Machine


Company Profile

   Our company was founded in 1996, factory area is around 95,000 square meter with fixed assets around 80 million, 600 workers and 120 experienced technicians. Annual output of plastic machinery is more than 3,000 sets and plastic products 50,000 tons. It is the first medium enterprise in western China to introduce the advanced technology from Germany, Italy, Japan and other countries to develop and innovate on the plastic machinery by themselves. It is the technical support unit of South China University of Technology-Polymer New Molding Equipment of National Engineering Research Center and the Nation Compound &modification Polymer Engineering and Technological Research Center.
 JC group as the earliest company to make and innovate the plastic machinery in China is professional to make EPE foam board, sheet, pipe, rod, profile,net production line; CO2-XPS foam board production line; plastic netting machinery; EPP physical foam automobile interior board production line; EPE color-film coating machine; LDPE air bubble film machine, etc. Our domestic market share has been accounted for 70%. We also export to Turkey, Romania, Mexico, India, Indonesia, Malaysia, Thailand, Vietnam, Russia, the United States, etc.
    We sticks to the principles of Quality First, Credibility First and Service Best to offer the best quality and most competitive price on the plastic machinery, warmly welcome the old and new customers to consult!





Specification

1. List of major equipments
A. Steel rack structure: 1set
B. Auto feeding unit: 1set
C. Extruding unit: 1set
D. Foaming agent injection unit: 1set
E. Anti-shrink injection unit: 1set
F. Foaming mold-head unit: 1set
G. Auto replacing net device system
H. Air ring & molding drum unit: 1set
I. Expanding unit: 1set
J. Haul-off unit: 1set
K. Rolling unit: 1set
L. Auto control unit: 1set
M. Adding nucleating agent unit: 1set
2. Major design data
Resin applied: LDPE
Capacity of squeezing engine: about 250-400kg/hr
Thickness of sheet: about 2-14mm
Width of sheet: about 600-2000mm (depending on thickness of sheet)
Speed of production line: 10-80m/min
Specifications of power: three phrases
3. Demands of Public Project
Electric power: about 220kw
Cooling water: 300L/Hr
Butane gas: 100L/H+100L/H (200L/H)
