Plastic Machinery

Home > Product > Film Blowing Machine

High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)

Ruian Queensense Machine Co., Ltd.
  • After-sales Service：1
  • Warranty：1
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1200mm
  • Screw Diameter：65mm

Base Info

  • Model NO.：SJ-B50,55,65,65-1)
  • Machine Weight：2.5t
  • Certification：CE
  • Rewinding：Double
  • Die：360°rotary
  • Suitable Material：HDPE,LDPE
  • Max Output：35-80kgs
  • Transport Package：Wooden Box
  • Specification：CE
  • Trademark：QUEENSENSE
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：35-80kg,H

Description

High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)


ModelSJ-B50SJ-B55SJ-B65SJ-B65-1
Screw Diameter50mm55mm60mm65mm
Screw Ratio(L/D)28: 128: 128: 128: 1
Screw Speed10-100r/min10-100r/min10-100r/min10-100r/min
Power of Main Motor Max Output11Kw 35kg/h15Kw 50kg/h15-18.5Kw 65kg/h18.5-22Kw 80kg/h
Max. Folding Width of Film600mm800mm1000mm1200mm
Single-sided Thickness of Film0.01-0.10mm0.01-0.10mm0.01-0.10mm0.01-0.10mm
Total Power22Kw26Kw30Kw36Kw
Weight of Machine2T2.3T2.6T3T
Overall Dimensions4000 x 1800 x 4600mm4200 x 2000 x 4900mm4600 x 2300 x 5600mm4800 x 2500 x 5800mm
High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)High & Low Rotary Die Head & Double Winder Film Blowing Machine (SJ-B50-65)
