• Model NO.：WSZL series
• Capacity：50 Sets Per Month
• Key Word 1：Plastic Grind Machine
• Key Word 2：Plastic Machine
• Key Word 3：Plastic Grinder Machine
• Transport Package：Wooden Cases
• Specification：1 cubic
• Trademark：WSZL
• Origin：Henan
• HS Code：8474809090
• Production Capacity：60-250kg H

Basic Info.

Model NO. WSZL series Capacity 50 Sets Per Month Key Word 1 Plastic Grind Machine Key Word 2 Plastic Machine Key Word 3 Plastic Grinder Machine Transport Package Wooden Cases Specification 1 cubic Trademark WSZL Origin Henan HS Code 8474809090 Production Capacity 60-250kgH

Product Description

China Waste Plastic Grinding Milling Granulator making machine


Model 150 Plastic Grinding Milling Granulator
The machine adopts Japanese design principles, employs the principles of grinding rapidly, agitating continuously, milling and fractioning to be heated with multi-knives and cooling and contracting. It produces granules from waste materials and angle materials such as the plastic films, filament, ribbons, pieces, soft plastic pipes, foaming materials, and degrading materials, and puts then into reproduction .It is the latest ideal granulating equipment to recycle plastics and reproduce.

Main Functions:
1. Recycle the waste materials and leftover bits and pieces of various flexible plastic films, bags, filament, ribbons, pieces, and pipes such as polyvinyl chloride, polyethylene of higher density, and linear polyethylene of lower density, and put them into reproduction.
2. Recycle and reproduce the grinding and granulating of degrading plastic films and angle materials.
3. Grind chemical fiber waste materials, and process the waste filament that has been put into reproductions.
4. The machine is applied in many respects. It can be substitute for blending machine or dryer.

Main Features:
A: Milling, mixture and staining can be processed all in one
B: The machine takes up little area of land
C: It is characterized by simple structure and ease of operation
D: The interstitial of the blade can be adjusted with convenience of replacing.
E: It is characterized by high efficient in production and low consumption(1 ton of daily production ,and 200 degrees of electricity consumption ).
F: Granulate at lower temperature, do not damage molecular structure of materials basically, and do not damage physical performance.

Plastic flakes grinding and milling combined granulator machine

Model	WSZL-150	WSZL-100	WSZL-500	WSZL-300
volume of machine	150L	100L	500L	300L
Capacity	60-80kg/h	30-60kg/h	300-400kgh	200-250kgh
Power of motor	18kw	15kw	55kw	37kw
Water setting	125w	125w	125w	125w
Heating motor	1.5kw	1.5kw	1.5kw	1.5kw
Rotating speed	660r/min	660r/min	660rmin	660rmin
size	1500×700×1400mm	1300×600×1300 mm	2300*1200*1600mm	2000x1000x1400mm
