Semi-Auto Water Bottle Blow Molding Machine in China
Zhangjiagang Links-Machine Co., Ltd.- Type：Stretch Blow Molding Machine
- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Non-Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, QS, UL, GMP
Base Info
- Model NO.：LK-1500
- Model：Lk-1500
- Control System：Computerized
- Bottler Material：Pet
- Bottle Volume：100ml to 1500ml
- Machine Capacity：1500 Bottles Per Hour
- Machine Installation Power：30kw
- Suitable for：Water Bottle, Beverage Bottle, Oil Bottle...Ect
- Workers Requests：3 Workers
- Certificate：SGS, ISO, Ce,..
- Weight：1200kgs
- Transport Package：Wooden Export Package
- Specification：ISO, SGS, CE
- Trademark：LINKS
- Origin：Zhangjiagang City, China
- HS Code：84774010
- Production Capacity：10,Month
Description
Blowing machine*2Dimension mm 1600*600*1610mm Weight kg 500 Bottle volume (max) ml 2500 Bottle volume (min) ml 50 Bottle Neck Diameter (max) mm 40 Bottle Neck Diameter (min) mm 18 Body Diameter (max) mm 125 Body Height( max) mm 420 Number of Cavities mold 2 Production output pcs/h 1600-1800BPH Clamping force T 5.7(56KN) Mold thickness mm 200(max) Mold width mm 360x390 Space between Tie-bars mm 120-220 Diameter of Tie-bars mm 63 Scope of Tie-bars mm 405 Mold stroke mm 160 Stretching stroke (max) mm 420 Working pressure Mpa 0.8-1.0Mpa Blowing pressure Mpa 2.0-3.0Mpa Power V/KW 1KW Weight Kg 500 Pre-heater
Dimension mm 1870*630*1450mm Weight kg 260 Power V/KW 14KW
Wooden Package Standard Export Request
FAQ
1) Can your factory provide the whole plant from A to Z?
A: Yes, we can provide the complete plant, from bottling making plant, water purification plant, to filling packing plant.
2) How can I know the machinery quality before I order?
A: Frist, we will invite you visiting our factory to check the machines quality, and show the machines running for you in our factory.
3)What certificates you can provide?
A: Our factory provide the CE, SGS, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect
4)Can your factory make the bottle drawing, workshop layout, and labels for us?
A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
(Workshop need customer to provide the size of factory)
5)Installation and Training Time
A: We have professional engineer for oversea installaion and training, they can speak English, and have much experience oversea work.
Wooden Package Standard Export Request
FAQ
1) Can your factory provide the whole plant from A to Z?
A: Yes, we can provide the complete plant, from bottling making plant, water purification plant, to filling packing plant.
2) How can I know the machinery quality before I order?
A: Frist, we will invite you visiting our factory to check the machines quality, and show the machines running for you in our factory.
3)What certificates you can provide?
A: Our factory provide the CE, SGS, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect
4)Can your factory make the bottle drawing, workshop layout, and labels for us?
A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
(Workshop need customer to provide the size of factory)
5)Installation and Training Time
A: We have professional engineer for oversea installaion and training, they can speak English, and have much experience oversea work.
