Professional Manufacture Customerized High Output and Quality ABA Polyethylene Film ...
Zhejiang Songshan Machinery Co., Ltd.- Screw Diameter：55mm*2PCS
- Certification：Ce ISO SGS
- Film：Wenzhou Ruian ABA Blown Film Extruder
- Condition：New
- Ld Ratio：30:1
- Warranty：One Year Guarantee
Base Info
- Model NO.：ABA-1400
- Motor：22kw
- Output：100kgs,H
- Automatic：No
- Blow Moulding Type：Extrusion Blow Moulding
- Blower：5.5kw
- Power(W)：25kwx2
- Transport Package：Plastic Film, , Wooden Boxes, , or as Required
- Trademark：songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
ABA-900
ABA-1200
ABA-1400
main material
HDPE
film width
800mm
1000mm
1200mm
output
60kgs/H
75kgs/H
100kgs/H
screw diameter
45mm×2pcs
50mm×2pcs
55mm×2pcs
gearbox
146
146
173
motor capacity
15KW
18.5KW
22KW
die size
60mm
80mm
100mm
air blower
2.2KW
3KW
5.5KW
roller width
900mm
1200mm
1400mm
taking up speed
0-60m/min
winding type
fraction type single winder
winding diameter
650mm
Dimension
4×3×4.5M
4×3.5×6M
4.5×4×7M
Low pressure polyethylene (HDPE) and linear low density polyethylene (LLDPE) are new varieties of polyethylene in the international market. It has advantages of impact strength, penetration-resistance, environmental stress crack resistance, and low temperature resistance, especially it can be used to make micro-thin films (the film strength of 0.015 mm film is as much as that of 0.03mm high-pressure polyethylene film).
Reworked materials or other affordable materials like 50% calcium carbonate can be used without affecting the strength, weldability, printing properties of the products; and the cooling becomes faster and the yield is higher because of the calcium carbonate or low pressure polyethylene in the interlayer.
