• Model NO.：SJSS-65
• Automatic：No
• Blow Moulding Type：Extrusion Blow Moulding
• Blower：2.2kw
• Temperature Control：5zones
• film Width：800mm
• Transport Package："Plastic Film; , Wooden Boxes, or as Required"
• Trademark：Songshan
• Origin：China (Mainland)

Model

SJSS-55

SJSS-60

SJSS-65

Features

Raw Material

PP

Output

30Kgs

50Kgs

60Kgs

Film Width

400mm

600mm

800mm

Film Thickness

0.008mm-0.1mm

Power supply

380V, 3Phase, 50Hz

Machine weight

2000kg

3000kg

3500kg

Dimension

6x1.5x4m

6x1.7x5m

6x2.5x5m

Extrusion Unit

Screw& Barrel Diameter

55mm

60mm

65mm

Screw& Barrel L/D ratio

30:1

Motor

15KW

18.5KW

22KW

Gearbox

146

173

173

Die Head Type

Rotary Die Head

Die Size

150mm

250mm

300mm

Heating

15KW

18KW

22KW

Blower

2.2KW

Film Traction
Unit

Roller Length

600mm

800mm

1000mm

Traction Motor

1.5KW

Winding Station

Winder Type

Single winding Station
Or Double winding Station

Rollers

600mm

800mm

1000mm

Torque Motor

15N/M

Max. Winding Diameter

600mm

Control Panel

Electronics

Top China Brand

Inverter Capacity

15KW/1.5KW

18.5KW/1.5KW

22KW/1.5KW

Optional Equipment

Hopper loader, Corona, Oven Dryer
