• Model NO.：ABA-900
• Automatic：No
• Blow Moulding Type：Extrusion Blow Moulding
• Blower：2.2kw
• Power(W)：18.5kwx2
• Gearbox：146
• Film：Wenzhou Ruian ABA Film Blowing Machine
• Transport Package：Plastic Film, , Wooden Boxes, or as Required
• Trademark：songshan
• Origin：Zhejiang, China (Mainland)

Model

ABA-900

ABA-1200

ABA-1400

main material

HDPE

film width

800mm

1000mm

1200mm

output

60kgs/H

75kgs/H

100kgs/H

screw diameter

45mm×2pcs

50mm×2pcs

55mm×2pcs

gearbox

146

146

173

motor capacity

15KW

18.5KW

22KW

die size

60mm

80mm

100mm

air blower

2.2KW

3KW

5.5KW

roller width

900mm

1200mm

1400mm

taking up speed

0-60m/min

winding type

fraction type single winder

winding diameter

650mm

Dimension

4×3×4.5M

4×3.5×6M

4.5×4×7M

Because of its low cost, it is widely used in the production of films. It can blow 3 kinds of polyethylene film including low pressure, high pressure and linear low density film. Meanwhile, It can blow films with new materials as well as reworked plastics with stable performance and reliable quality. This type machine applies a extruder with a special screw structure; advanced screw die head, flexible cooling wind ring, and reasonable fixed iris structure can ensure a good proportion of 3 mixed polyethylene materials.Reworked materials or other affordable materials like 50% calcium carbonate can be used without affecting the strength, weldability, printing properties of the products; and the cooling becomes faster and the yield is higher because of the calcium carbonate or low pressure polyethylene in the interlayer.
