High Speed HDPE 10zone ABA Film Blowing Machine Film Extruder Machinery with SGS

Zhejiang Songshan Machinery Co., Ltd.
  • Screw Diameter：55mm*2PCS
  • Certification：SGS
  • Film：Wenzhou Ruian ABA Film Blown Machine Extruder
  • Condition：New
  • Ld Ratio：30:1
  • Warranty：12 Months

Base Info

  • Model NO.：ABA-1200
  • Motor：18.5kw
  • Output：75kgs,H
  • Automatic：No
  • Blow Moulding Type：Extrusion Blow Moulding
  • Blower：3kw
  • Power(W)：22kwx2
  • Transport Package：Plastic Film, , Wooden Boxes, , or as Required
  • Trademark：songshan
  • Origin：Zhejiang, China (Mainland)

Description

Model

ABA-900

ABA-1200

ABA-1400

main material

HDPE

film width

800mm

1000mm

1200mm

output

60kgs/H

75kgs/H

100kgs/H

screw diameter

45mm×2pcs

50mm×2pcs

55mm×2pcs

gearbox

146

146

173

motor capacity

15KW

18.5KW

22KW

die size

60mm

80mm

100mm

air blower

2.2KW

3KW

5.5KW

roller width

900mm

1200mm

1400mm

taking up speed

0-60m/min

winding type

fraction type single winder

winding diameter

650mm

Dimension

4×3×4.5M

4×3.5×6M

4.5×4×7M
