Sj-50 LDPE & HDPE Film Blowing Machine

RUIAN YUNBANG MACHINE CO., LTD.
  • Type:PE Film Blowing Machine
  • Raw Material:PE
  • Maximum Folding Width of Film:600mm
  • Screw Diameter:50mm
  • Automation:Automatic
  • Computerized:Computerized

Base Info

  • Model NO.:SJ
  • Machine Weight:1.5t
  • Certification:CE, ISO9001:2008
  • Motor:11kw
  • Material:HDPE or LDPE
  • Power of Traction Motor(Kw):1.1
  • Max. Extrusion(Kg/H):35
  • Transport Package:as Requirement
  • Specification:CE. SGS
  • Trademark:YunBang
  • Origin:China
  • HS Code:8477309000
  • Production Capacity:20 Sets,Month

Description

Basic Info.

Model NO. SJ Machine Weight 1.5t Certification CE, ISO9001:2008 Motor 11kw Material HDPE or LDPE Power of Traction Motor(Kw) 1.1 Max. Extrusion(Kg/H) 35 Transport Package as Requirement Specification CE. SGS Trademark YunBang Origin China HS Code 8477309000 Production Capacity 20 Sets/Month

Product Description

SJ-50/55/65/65-1 PE High & low-pressure Film Blowing Machine

Use:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.

OPTIONAL EQUIPMENT:
1) AUTO LOADER
2) AIR SHAFT
3) ROTARY DIE DEVICE
4) DOUBLE SIDES WINDER
5) UP AND DOWN
6)PNEUMATIC DEVICE
7)AIR COMPRESSOR

Main Technical Variables:
ModelA50A55A65A65-1
Diameter of screwΦ50Φ55Φ60Φ65
Reduced diameter of film(mm)100-600200-800300-1000400-1200
Single-face thickness of
film(mm)
0.01-0.100.01-0.100.01-0.100.01-0.10
Max. Extrusion(kg/h)35506580
L/D28:128:128:128:1
Power of main motor(kw)7.5-1111-1518.5-2222
Power of Traction motor(kw)1.11.11.51.5
Heating Power(kw)11131921
Outline diameter(L*W*H)(mm)4800*1900*35005500*2100*38006500*2300*42006500*2500*6000
Weight(T)1.5T2T2.3T2.6T
