Sj-PP Film Blowing Machine

Wenzhou Wandun Machinery Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Type：PP Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1200mm
  • Screw Diameter：65mm

Base Info

  • Automation：Automatic
  • Computerized：Computerized
  • Machine Weight：2t
  • Certification：CE, ISO9001:2008
  • Transport Package：Wooden Pallet and Easy Film
  • Specification：4200 x 2000 x 4000mm
  • Trademark：WT
  • Origin：China

Description

TypeWTPP-55WTPP-60WTPP-70Diameter of screwΦ55Φ60Φ70L/D28:128:128:1Folding width of film(mm)100-500100-600300-800Single-face Thickness of film(mm)0.01-0.10.01-0.10.01-0.1Max. Extrusion(kg/h)304560Power of main motor(kw)111518.5Power of Traction motor(kw)1.11.11.5Length of Traction roller(mm)550650850Outline diameter(L×W×H)4500×2000×42004800×2500×45005000×2800×5000Weight(T)345
