ABA Three Layers Co-Extrusion PE HDPE LDPE PLA Film Blowing Machine
HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.- Type:High and Low Pressure Film Blowing Machine
- Raw Material:PE
- Maximum Folding Width of Film:1200mm
- Screw Diameter:65mm
- Automation:Automatic
- Computerized:Computerized
Base Info
- Model NO.:CHSJ-50,65ABA
- Machine Weight:4T
- Certification:CE, ISO9001:2008
- Packing Details:Wooden Cases
- Delivery Time:20-25 Working Days
- Extrusion Capacity Kg/H:98-150kg
- Material:LDPE, HDPE, LLDPE, Mlldpe
- Maximum Rotation Speed of Screw:120,Min
- Traction Speed M:15-70,Min
- Transport Package:Wooden Cases
- Specification:SGS
- Trademark:CHENGHENG
- Origin:China
- HS Code:8477309000
- Production Capacity:20-100PCS,Year
Description
CHSJ-50RCHSJ-55R Diameter of screw 50mm ×2 65mm×2 L/D ratio of screw 30:1 28:1 Main motor power (KW) Level 4 15×2 Level 4 22×2 Heating power(KW) 23.4 25 Film width(folding diameter) 300-800 300-1200 Film thickness(mm) 0.007-0.05 0.007-0.05 Extrusion capacity kg/h 98kg 120kg Maximum rotation speed of screw 120/min 120/min Traction speed M 15-70/min 15-70/min Winding speed M 30-80/min 30-80/min Raw material LDPE,HDPE,LLDPE,MLLDPE Machine power(KW) 37.5 40 Overall dimension 4.5×3.2×3.8 4.5×3.6×4.5 Weight 3.5T 4.2T
Our taiwan company partner. we are producing taiwan quality machine and 5 years garrantte and better price.
Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
Any need please contact me:
Our taiwan company partner. we are producing taiwan quality machine and 5 years garrantte and better price.
Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
Any need please contact me:
