PE Single Wall Corrugated Pipe Machine
Qingdao Suke Machinery Co., Ltd.- Product Type：PP Pipe
- Screw No.：Single-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Customized：Customized
Base Info
- Model NO.：SJ65x30
- Condition：New
- Material：Stainless Steel
- Screw Diameter：65mm
- Max. Output：120kg,H
- Plastic Machine Production Speed：1.5-10m,Min
- Barrel Heating：4 Sections
- Length of Vacuum Sizing Platform：6000mm
- Warranty：12monthes
- After Sale Service：Life Long with Professional After Sale Team
- Machine Control：Automatic
- Inverter：ABB
- Transport Package：as Export Standard for Plastics Machine
- Specification：ISO9000 CE
- Trademark：suke
- Origin：Qingdao, China
- HS Code：84775900
- Production Capacity：30sets,Year
Description
Single Wall Corrugated Pipe Production LineExtruder SJ-65/25 SJ-90/25 SJ-120/25 Range of Pipe Dia. 16-50 (mm) 65-115 (mm) 115-175 (mm) Water Consumption 2000 (L/H) 4000 (L/H) 5000 (L/H) Water Pressure 0.4-0.6 (Mpa) 0.4-0.6 (Mpa) 0.4-0.6 (Mpa) Number of Mold Blocks 40 (Paris) 50 (Paris) 60 (Paris) Total Length of Mold Blocks 2400 (mm) 5180 (mm) 6216 (mm) Speed of Mold Blocks 1-8 (m/min) 1-12 (m/min) 1-8 (m/min) Dimentions (L× W× H) (Approx) 10× 1...25× 1.5 (m) 18× 1.35× 1.7 (m) 21× 1.55× 2.2 (m) Total Weight (Approx) 3 (Ton) 6 (Ton) 9.5 (Ton)
