• Model NO.：HY-510580B
• Raw Material：Hops,PS,PVC,Pet
• Application：Plastic Packing
• Brand Name：Hongyin
• Model Number：Hy-510580b
• Processing Type：Plastic Thermoforming Machine
• Product Type：Plastic Packaging
• Transport Package：Wooden Packing
• Specification：CE
• Trademark：HongYin
• Origin：Zhejiang Ruian
• Production Capacity：50 Sets ,Year

Basic Info.

Model NO. HY-510580B Raw Material Hops/PS/PVC/Pet Application Plastic Packing Brand Name Hongyin Model Number Hy-510580b Processing Type Plastic Thermoforming Machine Product Type Plastic Packaging Transport Package Wooden Packing Specification CE Trademark HongYin Origin Zhejiang Ruian Production Capacity 50 Sets /Year

Product Description

HY-510580B Semi-Automatic Plastic Thermoforming Machine


I. Introduction with the machine:
HY-510580B semi automatic plastic thermoforming machine is a combination of mechanical, electrical and pneumatic components, and the whole system was controlled by a micro PLC, which can be operated in man-interface.
It combines the material sending, heating, forming info one process. It has three operation models. " manual", " semi-automatic" and "automatic, so it is a new generation ideal package equipment telecommuting and memory reserve functions.

II. Application areaof semi-automatic forming machine:
It is suitable to form BOPS, HIPS, PS, PVC and PET plastic sheets etc., which can produce various of boxes, dishes, trays, bowls and lids, such as food boxes, cake boxes, fast-food boxes, supermarket trays, oral liquids trays etc.

III. The semi-automatic forming machine main introduction:
1. Control system:
Whole machine adopts PLC to control the production technical process, tail remember of modern computer.

2. Automatic feeding sheet:
Large alone diameter cylinder type automatic material feeding frame. It can put one rolls material into the feeding frame in advance, about feeding there has two traction roll to translate the sheet that assurance of high speed operation and stability and correctness Greatly saves manpower and Ensure the smooth feed material at a high speed.

3. Heating part:
Heater adopts high quality heating plate to heating. The heat plate heating evenly and close to the sheet, it can keep the plastic sheet to heating enough and can be better for forming.

4. Mold forming and cuuting:
The vacuum machine is adopt positive pressure forming, it can combine the alone cutting machine to finshed punching edge.

5. The product cooling:
The machine is equipped with wind cool, water cool chasis and high speed cold water spraying device to speed up molding in order to assure the quality of moldings. Cooling delay, cooling time, Water spray delay, spray time, adjust the length of the time according to different products.


1Forming area:510×580mm	2Forming depth:100mm
3Sheet thickness range:0.1-1.2mm	4Sheet roller diameter:710mm
5Semi-automatic: Yes	6Ari pressure:0.7Mpa
7Water consumption: Liters/min(15-20ºC)	8Air consumption:1800 Liters/min
9Speed:600-1500 Liters/min	10Power:3-N AC380V±10%  50HZ
11Preheater power:2kw	12Mould plate heating power:4.8kw
13Heating plate power:15kw	14Sheet width:650mm
15Weight:2000kg	16Dimension(L×W×H): 4150×1150×2160×(mm)

IV. About Ruian Hongyin Machinery Co., Ltd Service.
1. Purchase Service
Ruian Hongyin Company have a specialize and efficiency working team. If you are new on the printing and packing area, Some samples of your products could be shew to us will be appreicate, we will give you specialized suggestion of whole work.

2. Installation Service:
Hongyin company will assigned 1 technician to coordinate installation, commissioning and training, cost for return flight and suitable accommodation will be charged, and the allowance is USD 80-100 per day.

3. Warranty Service:
12 months limited warranty.
Starting from the date of machine arrival buyer's place excluding wear parts.
Shipping cost for easy broken parts to be replaced during warranty period have to be borne by the customer.

If you are interested in our machine, please feel free and contact me.
