How to draw AutoCAD arrows
Drawing arrows in AutoCAD is a common requirement in engineering drawing and design. Whether it is dimensioning or indicating direction, the drawing of arrows is crucial. This article will introduce in detail how to draw arrows in AutoCAD, and attach popular topics and hot content for the past 10 days to help you quickly master this skill.
Table of contents
1. Basic methods for drawing AutoCAD arrows
2. Draw arrows with multiple leads
3. Custom arrow style
4. Hot topics and hot content in the past 10 days
1. Basic methods for drawing AutoCAD arrows
In AutoCAD, drawing arrows are usually done by the "Polyline" command (PLINE). The following are the specific steps:
- Open AutoCAD, enter the "PLINE" command, and press Enter.
- Specify the starting point and enter "W" to set the line width.
- Set the starting point width to 0 and the end point width to the width of the desired arrow (e.g. 2).
- Specify the length of the arrow to complete the drawing of the arrow.
2. Draw arrows with multiple leads
Multi-lead (MLEADER) is a commonly used annotation tool in AutoCAD, which can quickly draw leads with arrows. The following are the steps:
- Enter the "MLEADER" command and press Enter.
- Specifies the starting point and end point of the lead.
- Set the arrow style and size in the pop-up dialog box.
- After the label is completed, the arrow will be automatically generated.
3. Custom arrow style
AutoCAD allows users to customize arrow styles to meet different design needs. The specific steps are as follows:
- Enter the "DIMSTYLE" command to open the Dimension Style Manager.
- Select the Modify button to enter the Symbols and Arrows tab.
- In the Arrows section, select the desired arrow style or custom arrow.
- After saving the settings, you can use the custom arrows.
