• Model NO.：SJSZ65,132
• Customized：Customized
• Condition：New
• Sheet Width：600-2000mm
• Sheet Thickness：0.8-3mm
• Application：Waterproof and Heat Preservation Sheet. Edge Band
• Extruder Model：Conical Twin Screw Extruder
• Die Head：Jc-Times
• Calibrating：Three Roller Calendar Technology
• Main Electrical Parts：ABB, Omron, Rkc, Schneider, FUJI, Delix etc.
• Guaranteed Time：1 Year
• Quality Control：Customers Come to Our Factory to Check
• Transport Package：Separate Wood Case and Pallet
• Specification：ISO9001-2000
• Trademark：LEADER
• Origin：Qingdao China
• HS Code：8477209000
• Production Capacity：40set,Year

PAR T1  THIS LINE CONSISTS OF (COMPULSORY)1Automatic spring feeding machine1 set2Conical twin screw extruder1 set3T-type /hanger type die head (JC-Times brand)1 set4Three Roller Calendars (alloy steel material )1 set5Rollers thermoforming machine1 set6Cooling frame and edge cutting unit1 set7Haul off machine1 set8Plastic cutting machine-Guillotine1 set9Twin position winder1 set10Spare parts1 set PART 2  ACCESSORY MACHINE PARTS (OPTIONAL)11High speed hot and cold mixer1 set12Plastic crusher1 set13Plastic pulverizer1 set14Air compressor1 set15Industrial water chiller1 set PART 3 SHEET SPECIFICATIONS1Sheet width500-1500mm2Sheet thickness0.5-2mm3TypeRigid pvc, untransparent PART 4 SHEET APPLICATIONS1Sandwich panel, furniture edge band, thermoforming packing PART 5 PAYMENT, DELIVERY AND AFTER SALE SERVICES1Payment terms40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable2Delivery time60 days after receipt of prepayment3Packing methodWooden cases/pallets with stretching films4Guaranteed time18 months for mechanical parts, 12 months for electrical parts5After sale serviceSend 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable6ContactMs Lilly Zhou (mob: 0086-15266238607)

Model	LMSB65/132	LMSB80/156	LMSB92/188
Max product width	1000mm	1500mm	2000mm
Products thickness	0.5-3mm	0.5-3mm	0.5-3mm
Extruder model	SJ-65/132	SJ80/156	SJ-92/188
Rollers diameter	350mm	400mm	450mm
Rollers temperature control	Oil/water	Oil/water	Oil/water
Main motor power	37kw	55kw,75kw	75kw, 110kw
Capacity	250kg/h	360kg/h	550kg/h
Total line Length	22m	28m	35m

PART 5 COMPANY INFORMATION AND MAIN PRODUCTS:




PART 6 COMPANY CERTIFICATIONS:

PART 7 MACHINE PACKING AND DELIVERY
All the machine parts will be packed in wooden cases or pellets with stretching films on machine body.
