Wenzhou Professional Manufacture Easy Control Sjss Ce Certification Water Cooling PP Film ...
Zhejiang Songshan Machinery Co., Ltd.- Certification：CE
- Condition：New
- Warranty：1year Guarantee
- Motor：15kw
- Output：30kgs
- Automatic：No
Base Info
- Model NO.：SJSS-55
- Blow Moulding Type：Extrusion Blow Moulding
- Temperature Control：5zones
- Blower：2.2kw
- film Thickness：0.008mm-0.1mm
- film Width：400mm
- Transport Package："Plastic Film; , Wooden Boxes, or as Required"
- Trademark：Songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
SJSS-55
SJSS-60
SJSS-65
Features
Raw Material
PP
Output
30Kgs
50Kgs
60Kgs
Film Width
400mm
600mm
800mm
Film Thickness
0.008mm-0.1mm
Power supply
380V, 3Phase, 50Hz
Machine weight
2000kg
3000kg
3500kg
Dimension
6x1.5x4m
6x1.7x5m
6x2.5x5m
Extrusion Unit
Screw& Barrel Diameter
55mm
60mm
65mm
Screw& Barrel L/D ratio
30:1
Motor
15KW
18.5KW
22KW
Gearbox
146
173
173
Die Head Type
Rotary Die Head
Die Size
150mm
250mm
300mm
Heating
15KW
18KW
22KW
Blower
2.2KW
Film Traction
Unit
Roller Length
600mm
800mm
1000mm
Traction Motor
1.5KW
Winding Station
Winder Type
Single winding Station
Or Double winding Station
Rollers
600mm
800mm
1000mm
Torque Motor
15N/M
Max. Winding Diameter
600mm
Control Panel
Electronics
Top China Brand
Inverter Capacity
15KW/1.5KW
18.5KW/1.5KW
22KW/1.5KW
Optional Equipment
Hopper loader, Corona, Oven Dryer
