High Speed Rotary Die Plastic Film Blowing Machine Blown Film Machine

Ruian Queensense Machine Co., Ltd.
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1200mm
  • Screw Diameter：50mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：QS-AH50,55,60,65
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008, UL, QS
  • Max.Extrudsion Output：HD50kg,H,Ld60kg,H
  • Die Size：60-120mm
  • Film Width：100-600mm
  • Film Thickness：0.008-0.15mm
  • Transport Package：Seaworthy
  • Specification：CE SGS
  • Trademark：QUEENSENSE
  • Origin：China
  • HS Code：847780000
  • Production Capacity：2000PCS,Per Year

Description

Performance Introduction:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrided and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones. High Speed Rotary Die Plastic Film Blowing Machine Blown Film Machine

Optional equipment:HDPE/LDPE/LLDPEFILM WIDTH100-600MM200-800MM300-1000MM400-1200MMFILM Thickness0.008-0.15mm0.008-0.15mm0.008-0.15mm0.008-0.15mmmax.extrusion output60kg/h90kg/h110kg/h130kg/hscrew diameter (mm)50556065main motor(kw)22303745size(m)4.1*1.7*4.14.8*1.9*4.95.5*2.1*5.15.8*2.5*5.5
Optional equipment:

1). Auto load
2). Air compressor
3). Special die
4). Die rotary device
5). Bouble sides winder
6). Up and down
