Double Screws Stretch Film Extruder
Ruian Hoin Machinery Co., Ltd.- After-sales Service:Technical Support Online
- Warranty:One Year
- Type:Sheet Extruder
- Plastic Processed:PE
- Product Type:Profile Extrusion Molding Machine
- Feeding Mode:Multiple Feed
Base Info
- Model NO.:F2S-1000
- Assembly Structure:Separate Type Extruder
- Screw:Twin-Screw
- Engagement System:Full Intermeshing
- Screw Channel Structure:Deep Screw
- Exhaust:Exhaust
- Automation:Automatic
- Computerized:Non-Computerized
- Winder Control:Automatic Change
- Winder Station:Double Stations
- Material Loading:Auto Loader
- Waste Recycling:Optional Device
- Transport Package:Strech Film Wrapping and Wooden Box
- Specification:CE, ISO9001 certificate
- Trademark:HOIN
- Origin:Ruian, Zhejiang, China
- HS Code:8477301000
- Production Capacity:70kgs,H
Description
Basic Info.
Model NO. F2S-1000 Assembly Structure Separate Type Extruder Screw Twin-Screw Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Exhaust Automation Automatic Computerized Non-Computerized Winder Control Automatic Change Winder Station Double Stations Material Loading Auto Loader Waste Recycling Optional Device Transport Package Strech Film Wrapping and Wooden Box Specification CE, ISO9001 certificate Trademark HOIN Origin Ruian, Zhejiang, China HS Code 8477301000 Production Capacity 70kgs/HProduct Description
Any query welcome to contact with us.Ms.WendyPan
A. Product Specification:
- The most usage pallet packaging: Such as fertile, cement, chemical industrial raw material, building material etc.
- Horizontal packaging: Metal pipe, aluminum alloy material, timber etc.
- Rotational twist: Rolling paper, carpet etc.
- Binding: Glass container, acceptance etc.
- Break-bulk packaging: Soybean, grain, plastic particle etc.
- Storage packaging: Such as grass.
- Manual packaging: It is used in wholesales, journal, printing, electronic product, foodstuff etc.
- Ring twist packaging: Type, wire, cable, steel silk etc.
Model | F2S-1000 |
Applicable Materials | LDPE LLDPE |
Width of Film | 1000mm |
Thickness of Film | 0.015-0.05mm |
Max. Extrusion Output | 70kg/h |
Total Power | 80KW |
Weight of Machine | 4.6T |
Overall Dimension | 7*3.2*1.9M |
Screw Diameter | Φ55mm*2 |
Screw L/D Ratio | 30:1 |
Screw and Barrel Material | SAC-645/38CrMoALA |
Screw and Barrel Heating | Cast Aluminum |
Die Head Structure | Coat-hanger Die |
Die Head Material | 40Cr Mould Steel |
Length of Die Head | 1250mm |
Winder | Single Station Friction Winder |
Cooling Roller | Mirror Roller, Screw clamp Type, Recycling Cooling |
Traction Roller | Mirror Roller |
Winder Motor | 2.2kw, Inverter Control |





More Products Optional

1. How long will your engineer reach to our factory?
Within one week after machine arrival at your factory.
2. How many days will you finish installing?
We will finish installation and training within 15days.
3. What should we charge for your engineer?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary 100USDper day per person.
4. How long of your machine's warranty period?
Our machines have one year guarantee after finishing installation under normal operation.
5. How could we do after one year warranty period?
We will still offer you our best after service, of course you will afford our technician's cost.
6. How could we do if the parts broken within of after warranty?
We will express the free replacement parts during the warranty date and also send you parts needed by value after warranty.
7. Does your engineer understand English?
Our engineers understand a little English. All of our engineers have rich experience for installingmachines over seven years. In addition, they also can communicate with you using their body language vividly.
8. Can you find us any engineer in our location?
Of course, we will check and inform you as soon as possible.
