• Model NO.：DSB120
• Application：Drum, Plate, Float, Roadblocks, Medical Bed Board
• More Application：Road Barrier, Traffic Barriers, Tool Boxe
• Other：Autoparts, Car Bumpers, Car Spoilers
• Weight：38 T
• Output Capacity：20~25 PCS,H
• Plasticization：320~400 Kg,H
• Heating Zone：5~6 Aluminum Heater
• Heating Power：36kw,H
• Max Mould Size：1200X1800mm
• Electromagnetic Valve：Airtac
• Valves：Imported Oil Pump Valves and Connections
• Water Flow：18t,H
• Water Pressure：0.3-0.6MPa
• Max Volume：250L
• Suitable Material：PE
• Transport Package：Film Packing
• Specification：DSB120
• Trademark：Dawson
• Origin：Zhangjiagang
• HS Code：8477301000
• Production Capacity：2 Sets,Month

Basic parametersSuitable materialPEMax volume250LOutput capacity20~25 pcs/hSize8.6×3.8×5.8 (M)Weight38 TsystemSpecificationParametersNotePlasticizion systemSummarizeHigh efficient low power consumption plasticizion system,transducer control,self-protect function when started at low temperature ReducerHard finishing,High intension,Low noise reducer Screw∮120mm,L/D ratio 28, 38CrMoALACooling system availablePlasticization320~400 Kg/HHDPEHeating Zone5~6 Aluminum HeaterAutomatic heatingHeating power36KW/H Extrusion Motor Motor 132kw (380V,50HZ) Cooling Fan5~6zone        Automatic coolingExtrusion systemSummarizeHigh-grade alloy steel, center feeding Die head number1 Center distance of die heads/ Max die mouth∮600mm Heating zone6 Stainless steel heating cycle Clamping systemSummarize
 High intension, rigidity, center mold locking, stable mould opening and clamping system  Clamping force850~900KN Template distance850~1850mm Max mould size1200X1800mm Mould materialHigh grade 50# steel Electric systemSummarizePLC+ touch screen(man-machine interface)standard extrusion blow molding machine controlling system(AUTO monitoring, fault-alarm, auto counting ,auxiliary function available)
Japanese Mitsubishi PLC
systemOperate interfaceTouch screen, automatic self-diagnose alarm system Temperature controlAutomatic temperature control module Movement controlJapanese Mitsubishi, Chinese/English
Version Electric protectionAmpere overload, electric short circuit self-protection function Hydraulic systemSummarizeMultiple function hydraulic integrated block Proportional control, high efficient Oil pump motorThree phase asynchronous motor (380V/220V,50/60HZ) 22kw Oil pumpImported double pump ValvesImported oil pump valves and connections Oil pipesDouble layer overpressure resistant System pressure60Kg/cm² Cooling systemSeparate water cooling cycle, oil cooler cooling system Pneumatic systemSummarizeTaiwan AIRTAC pneumatic system Air pressure1Mpa Air displacement1.8M3/min Electromagnetic valveAIRTAC Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system Cooling mediumWater Water flow18t/h Water pressure0.3-0.6MPa
