Chsj-M Series Film Blowing Machine
HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.- Type：High and Low Pressure Film Blowing Machine
- Raw Material：HDPE
- Maximum Folding Width of Film：800mm
- Screw Diameter：45mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：CHSJ-M
- Machine Weight：4T
- Certification：CE, ISO9001:2008
- L/D Ratio of Screw：30:1
- Diameter of Screw：40,50mm
- Film Width(Folding Diameter)：100-800mm
- Packing Details：Wooden Cases
- Delivery Time：20-25 Working Days
- Payment Term：T,T
- Transport Package：Wooden Cases
- Specification：SGS
- Trademark：CHENGHENG
- Origin：China
- HS Code：8477309000
- Production Capacity：10PCS,Month
Description
CHSJ-45ACHSJ-50A Diameter of screw 40mm 50mm L/D ratio of screw 30:1 30:1 Main motor power (KW) Level 4 11 Level 4 15 Heating power(KW) 11.4 13.4 Film width(folding diameter) 100-500 260-800 Film thickness(mm) 0.007-0.05 0.007-0.05 Extrusion capacity kg/n 45 65 Maximum rotation speed of screw 150/min 150/min Traction speed M 15-70/min 15-70/min Winding speed M 30-80/min 30-80/min Raw material HDPELLDPE HDPELLDPE Machine power(KW) 27.5 31.9 Overall dimension 4.5×2.9×3.8 4.5×3.2×4.5 Weight 2.8 T 3.6T
Service:
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
Contact person:Shuping Wei
Mobil: 86-15097900873
Service:
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
Contact person:Shuping Wei
Mobil: 86-15097900873
